Via Matter (fully local)
Server for KNX New
569€ + VAT
999€ + VAT
Ships in 10-12 business days
Integrations
KNX to Apple Home
Via Apple Home (fully local)
Read more
KNX to Google Home
Via Matter (fully local)
Direct integration (via cloud)
Read more
KNX to Amazon Alexa
Supported in the future via Matter (fully local)
Direct integration (via cloud)
Read more
KNX to Samsung SmartThings
Supported in the future via Matter (fully local)
KNX to Home Assistant
Coming soon
SONOS
Planned for future updates
Loxone
Advanced functionality
Advanced logic module in 1Home dashboard
Coming in December 2023
Bring 100s of IoT devices to 1Home dashboard via Matter
Coming in February 2024
Integrated KNX IP interface
4 concurrent connections
6 concurrent connections
Project setup & maintenance
Automatic ETS device detection AI
Automatically detects devices such as lights, blinds etc. to save you hours of manually creating devices and typing in group addresses.
Improved overview and confirmation of automatically detected devices.
Configuration validation
Detects setup mistakes and incorrectly configured group addresses and alerts you during the project set up. This is a real life saver in decreasing the time on each project and making the customer happy when they move in.
Secure remote ETS programming
Remote installer dashboard
Built both for one-man installers as well as for large installer companies. Easy way to manage multiple installers across many different projects.
Basic remote dashboard to configure your projects.
General information
Local support
Fully local with local dashboard, no internet connection required.
Local execution of Apple Home, initial configuration and other integrations via cloud.
Device details
DIN mountable
Direct KNX bus connection or via KNXnet/IP tunnel interface
CPU: Quad core, up to 1.5 GHz
RAM: 1 GB
Storage: 8 GB on board
Power supply (not included with Server): 5W, external 12-30VDC or 12V 1A DC barrel
Future proof hardware, designed in-house
DIN mountable
Direct KNX bus connection or via KNXnet/IP tunnel interface
CPU: Single core, 454 MHz
RAM: 128 MB
Storage: 256 MB on board
Power supply: 1.5W, 12-30VDC, or via PoE
Based on Weinzierl BAOS777
Technical data sheet
Documentation & installation guide
